||0.01 to 20 L/min
||±2% of reading or 0.005 std. L/min, whichever is greater at standard conditions (21.1°C and 101.3 kPa)
|Operating Temperature Range
||0 to 50°C
||5 in. x 2 in. x 1.25 in.
||0.375 in. O.D. Straight
||Battery Pack, 7.5 VDC ± 1.5V, 300 mA max
1 Accuracy stated at standard conditions of 21.1°C and 101.3 kPa.
2 Accuracy stated with air temperature and flow body temperature within ±10°C of one another.
3 Accuracy stated measuring dry air (less than 10% R.H.).
4 Includes ±0.5% of reading repeatability.
5 Volumetric flow rate is calculated from the mass flow measurement. Add an additional 0.25% of reading to the flow accuracy to account for the uncertainty in measuring air temperature and pressure.
